1. Loosen and remove the upper pin.
2. Remove the door.
3. Remove the spacer.
4. With a key, loosen the lower pin.
On the opposite side:
1. Tighten the lower pin.
2. Install the spacer.
3. Install the door.
4. Tighten the upper pin.
Ventilation requirements
The airflow behind the appliance must be
sufficient.
min.
200 cm
2
min.
200 cm
2
Installing the appliance
Caution! Make sure that the mains
cable can move freely.
Do the following steps:
1. If necessary cut the adhesive sealing
strip and then apply it to the appliance
as shown in figure.
x
x
12 electrolux
