Fix the covers on the screws.
Do a final check to make sure that:
•All screws are tightened.
• The sealing strip is attached tightly to the
cabinet.
• The door opens and closes correctly.
ASSEMBLY INSTRUCTIONS FOR THE COMPENSATOR LOWER
PART OF THE DOOR
With the door open, loosen the two
screws situated in the lower part without
unscrewing them completely.
Position the steel compensator as indi-
cated in the figure and insert the upper
part under the head of the screws.
16
