31
Storage Features
Dividers Removal
Lift up on the front of the upper divider and
pull out.
Squeeze handle and lift up in the center
of the divider to move it side-to-side. (The
divider cannot be removed.)
Upper Basket Divider
Upper Basket
Divider
Retainers
Stabilizer
Bar
Plastic Lower Basket Divider
Lower Basket
Divider
Pull to Remove
Push to Replace
Removing Freezer Basket
Instructions
1 Locate the basket clips in the rear
corners of the basket and pull them
out to remove.
2 Open fresh food doors completely.
3 Lift the basket up and remove.
Replacing Freezer Basket
Instructions
1 Place freezer basket back inside the
freezer drawer.
2 Replace clips by sliding them back
into the slots.
Location of
basket clip.
One each side.
Tilt Wire Shelf
The freezer tilt wire shelf (located on
the inside of the freezer drawer) is not
designed to be removed.
