directly into the stand pipe.
4. To a stand pipe with vent-hole - Insert
the drain hose directly into a drain pipe.
Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter of
the drain hose.
5.Without the plastic hose guide, to a
sink spigot- Put the drain hose in the
spigot and tighten it with a clamp. Refer
to the illustration.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
6. Position the hose directly to a built-in
drain pipe in the room wall and tighten it
with a clamp.
ENGLISH 9
