38
GLMB209DB
GLMB209DS
GLMB209DQ
PLMB209DC
REF. NO. PART NO. DESCRIPTION Q'TY
42 FCOV-B272MRK0 Door frame assembly [GLMB209DQ] 1 AV
42 FCOV-B273MRK0 Door frame assembly [PLMB209DC] -deco included- 1 AV
43 LSTPPB021MRF0 Latch head 1 AD
44 MSPRTA046WRE0 Latch spring 1 AD
45 FDORFB075MRT0 Door panel [GLMB209DB/PLMB209DC] 1 AQ
45 FDORFB087MRT0 Door panel [GLMB209DS] 1 AQ
45 FDORFB088MRT0 Door panel [GLMB209DQ] 1 AQ
46 PSHEPB016MRE0 Sealer film 1 AE
47 GCOVHB047MRF0 Choke cover 1 AG
48 LSTPPB036MRF0 Door stopper 1 AA
49 PGLSPB076MRE0 Door glass [GLMB209DB/PLMB209DC] 1 AN
49 PGLSPB077MRE0 Door glass [GLMB209DS] 1 AN
49 PGLSPB078MRE0 Door glass [GLMB209DQ] 1 AN
50 LSTPPB036MRF0 Door glass stopper 1 AX
51 XEPSD30P06XS0 Screw 1 AX
MISCELLANEOUS
52 FW-VZB217MRE0 Main wire harnes 1 AT
53 FROLPB025MRK0 Turntable support 1 AN
54 NTNT-A099WRE0 Turntable tray 1 AM
55 TCAUAB050MRR0 Monitor caution label 1 AA
56 TCAUAB048MRR0 DHHS/Screw caution label 1 AB
57 TINSEB383MRR0 Operation manual 1 AD
58 QW-QZB016MRE0 High voltage wire A 1 AC
SCREWS,NUTS AND WASHERS
59 LX-BZA041WRE0 Special screw 5 AA
60 LX-CZ0052WRE0 Special screw 2 AA
61 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
62 XOTSE40P12000 Screw : 4mm x 12mm 11 AA
63 XCBSD30P08000 Screw : 3mm x 8mm 4 AA
64 XHTSD40P08RV0 Screw : 4mm x 8mm 3 AA
65 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AB
66 XOPSD40P12XS0 Screw 1 AA
67 XOTSF40P12000 Screw : Outercase screws [GLMB209DB] 4 AA
67 XOTSE40P12000 Screw : Outercase screws
[GLMB209DS/GLMB209DQ/PLMB209DC] 4AA
68 XOTSE40P12000 Screw : Outercase screws 2 AA
∆
∆
∆
