45
GLMV169DB
GLMV169DQ
GLMV169DS
PLMV169DC
REF. NO. PART NO. DESCRIPTION Q'TY
∆
∆
∆
55 LHLD-B012MRF0 Rack holder 2 AF
56 LSTPPB031MRF0 Door stopper 1 AC
57 PCOVPB076MRF0 Louver cover A 1 AG
58 PCOVPB077MRF0 Louver cover B 1 AG
59 PCOVPB078MRF0 Louver cover C 1 AG
60 PDUC-B098MRP0 Magnetron air guide 1 AC
61 LHLD-B016MRF0 Left rear holder 1 AF
62 LHLD-B017MRF0 Right rear holder 1 AF
DOOR PARTS
63 CDORFB366MRK0A Door assembly [PLMV169DC] 1 AX
63 CDORFB361MRK0A Door assembly [GLMV169DB] 1 AX
63 CDORFB362MRK0A Door assembly [GLMV169DS] 1 AX
63 CDORFB363MRK0A Door assembly [GLMV169DQ] 1 AX
64 FDORFB083MRT0 Door panel assembly [GLMV169DB/PLMV169DC] 1 AX
64 FDORFB084MRT0 Door panel assembly [GLMV169DS] 1
64 FDORFB085MRT0 Door panel assembly [GLMV169DQ] 1
65 FCOV-B267MRK0 Door frame assembly [GLMV169DB] (not available in S/S) 1 BD
65 FCOV-B268MRK0 Door frame assembly [GLMV169DS] 1 BD
65 FCOV-B269MRK0 Door frame assembly [GLMV169DQ] 1
66 PGLSPB072MRE0 Front door glass [GLMV169DB/PLMV169DC] 1 AQ
66 PGLSPB073MRR0 Front door glass [GLMV169DS] 1 AQ
66 PGLSPB074MRR0 Front door glass [GLMV169DQ] 1
67 LSTPPB030MRF0 Latch head 1 AC
68 LSTPPB032MRF0 Glass stopper 1 AC
69 MSPRTA046WRE0 Latch spring 1 AB
70 GWAKPB187MRR0 Door frame [GLMV169DB] (not available in S/S) 1 AZ
70 GWAKPB188MRR0 Door frame [GLMV169DS] 1 AZ
70 GWAKPB189MRR0 Door frame [GLMV169DQ] 1
71 FCOVHB005MRK0 Choke cover assembly 1 AH
72 PSHEPB024MRE0 Sealer film 1 AF
73 FHNDPB015MRK0 Door handle [PLMV169DC] 1 AL
73 JHNDPB049MRF0 Door handle [GLMV169DB] 1 AL
73 JHNDPB050MRF0 Door handle [GLMV169DS] 1
73 JHNDPB051MRF0 Door handle [GLMV169DQ] 1
74 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
75 XCPSD40P10000 Screw : 4mm x 12mm 2 AA
MISCELLANEOUS
76 CFZK-B131MRK0 Installation material assembly 1 AM
77 LBSHC0040MRE0 Grommet 1 AC
78 LX-BZ0195WRE0 Toggle screw 4 AC
79 LX-MZB001MRE0 Cord holder 1 AB
80 XBRSD50P60000 Screw : 5mm x 60mm 2 AC
81 XOTSD40P12000 Screw : 4mm x 12mm 1 AA
82 XTSSD50P35000 Screw : 5mm x 35mm 6 AA
83 XWHSD50-16300 Washer 2AA
84 TINSEB385MRR0 Installation instruction 1 AB
85 TINSEB380MRR0 Operation manual 1 AD
86 TINSKB047MRR0 Top template 1 AC
87 TINSKB048MRR0 Wall template 1 AB
88 QW-QZB023MRE0 High voltage wire A 1 AD
89 FW-VZB234MRE0 Main harness A 1 AU
90 TCAUAB048MRR0 DHHS/GRD/caution label 1 AA
91 TCAUAB050MRR0 Monitor caution label 1 AA
92 PFIL-B011MRE0 Charcoal filter 1 AH
93 PFIL-B010MRE0 Grease filter 2 AF
94 PCLICB003MRE0 Canoe clip 1 AA
95 UAMI-B009MRM0 Rack 1AR
96 QW-VZB010MRE0 Sensor gnd wire 1
SCREWS,NUTS, WASHERS AND MISC.
97 XOTSE40P12000 Screw : 4mm x 12mm 10 AA
98 XBTSD40P08000 Screw : 4mm x 8mm 2 AA
99 LX-CZA038WRE0 Special screw 4 AA
100 LX-CZ0052WRE0 Special screw 2 AA
101 LX-BZB012MRE0 Unit mounting screw 2 AD
102 XCBSD30P08000 Screw : 3mm x 8mm 6 AA
103 LX-BZA041WRE0 Special screw 9
104 LX-CZB024MRE0 Louver screw [GLMV169DS/GLMV169DQ] 3 AA
104 LX-CZB025MRE0 Louver screw [PLMV169DC/GLMV169DB] 3 AA
105 LANGTB055MRP0 Chassis support 2
106 LANGTB100MRP0 Chassis support gusset 4
