3.1 Dimensions
H1
H2
W1
D1
W2
D2
W3
D3
Overall dimensions ¹
H1* mm 1550
W1 mm 595
D1 mm 650
¹ the height, width and depth of the
appliance without the handle
* including the height of the top hinge (10
mm)
Space required in use ²
H2 mm 1700
W2 mm 695
D2 mm 744
² the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air
Overall space required in use ³
H2 mm 1700
W3 mm 982
D3 mm 1244
³ the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air, plus the space necessary
to allow door opening to the minimum
angle permitting removal of all internal
equipment
3.2 Location
This appliance is not intended to be used
as a built-in appliance.
In case of different installation from
freestanding respecting space required
in use dimensions, the appliance will
function correctly but energy
consumption might increase slightly.
