Evacuationsystem
15
6Evacuationsystem
6.1Airprinciple
T5130
Thefancreateslowpressureinthemachine,drawingairintothedrumviatheheatingunit.
Theheatedairpassesthroughthegarmentsandthedrumvents.
Theairthenowsoutthroughalintlterpositionedinthedoor.Afterthis,theairisevacuated
throughthefanandexhaustsystem.
Note!
Itisveryimportantthatthemachinegetsenoughfreshairinordertogetthebestdrying
result.
T5130C
Thecondensatemachinedoesnothaveevacuationofairintotheopen.
Theairiscirculatedinaclosedsystembetweenthemachineandthecondensingunit.Thewater
inthegarmentscondensesinthecondensingunitandisledouttothedrain.Thedrainhose
shallhangfreelywithagentlebend.
g.W00203A
