Element RC Enduro Ecto - Drive Shaft Assembly: Gate 02 (Bag 8); Drive Shaft Assembly: Gate 03 (Bag 8); Shock Assembly: Gate 01 (Bag 9)

DRIVESHAFT BUILD: BAG 8
GATE 02
DRIVESHAFT BUILD: BAG 8
GATE 03
13
33.664760, -117.676533
x4
42022
Screw Pin
THREAD L
OCK
#1596
THREAD L
OCK
#1596
THREAD L
OCK
#1596
THREAD LOCK
#1596
33
42
48
75
33
33
NOTE: Make sure the screw
pins are aligned with each
female CVA during assembly
NOTE: Make sure the phasing of the drive shafts is correct when installing
them to the axles and gearbox.
FRONT REAR
Correct Phasing
Incorrect Phasing
NOTE: Install the
front drive shaft
NOTE: Install the
rear drive shaft
SHOCK BUILD: BAG 9
GATE 01
x2
x1
x1
x1
x1
x2
x1
x1
x1
6299
E-Clip
42081
Shock
Piston
42040
Enduro
Rod Ends
42083
Shock Shaft,
3x30mm
42082
Shock Body,
Silver,
10x32mm
5407
O-Ring,
Red
42081
Shock O-Ring
Spacer
42080
Shock Bottom Cap,
Plastic
42081
O-Ring,
Shock Cap
SHOCK FL
UID
#5422
SHOCK FL
UID
#5422
NOTE: Build 4
complete shocks
SHOCK CAP
O-RING
SHOCK COLLAR
O-RING
*Not Included
*Not Included
*Not Included
*Not Included
x1
31392
3x5x0.3mm
Washer
