Element RC Utron SE - Chassis Drivetrain Components Installation; Gate 08: Drive Shaft Construction; Gate 09: Front Drive Shaft Mounting; Gate 10: Chassis Mounts and Rails

CHASSIS BUILD:
GATE 08
CHASSIS BUILD:
GATE 09
CHASSIS BUILD:
GATE 10
09
33.657120, -117.701139
x2
x1
x2
x1
x1
x1
x2
x2
x2
42021
Drive Shaft,
Male, CVA
42021
Pin,
2x11mm
42314
Drive Shaft, Female
(33mm, 42mm)
31532
3x8mm
BHCS
42314
Drive Shaft, Male
(46mm, 60mm)
42314
Pin Retainer,
Short
42020
Pin Retainer,
Long
42021
Drive Shaft,
Female, CVA
42021
Drive Shaft
Barrel
Rear (mm)
33
42
60
Front (mm)
33
33
46
Female 1
Female 2
Male
Drive Shaft Lengths
42020
Gearbox Side
42020
Axle Side
NOTE: Build a front
and rear drive shaft
THREAD LOCK
#1596
THREAD LOCK
#1596
NOTE: Install the
front drive shaft
NOTE:
Install the
x2
x1
x1
25211
3x10mm
BHCS
42257
Chassis Rail
Left
42022
Screw Pin
x1
x2
42305
Floor
Board
25211
3x10mm
BHCS
x2
x1
x1
x1
25211
3x10mm
BHCS
31532
3x8mm
BHCS
4689
3x16mm
Set Screw
31532
3x8mm
BHCS
x1
42314
Drive Shaft, Male
(46mm, 60mm)
x1
42022
Screw Pin
x1
x2
25203
3x12mm
FHCS
42304
Shock Mount
(Right, Front)
