Elenco Electronics Electronic Snap Circuits - Snap Circuits Components Guide; Core Building Blocks; Power and Control Components; Integrated Circuits (ICs)

Note: If you have the more advanced Models SC-300, SC-500, or SC-750, there are additional part lists in the other project manuals.
Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at:
help@elenco.com. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A.
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
r 1
Base Grid
(11.0” x 7.7”)
6SCBG
r 1
Red Light Emitting
Diode (LED)
6SCD1
r 3
1-Snap Wire 6SC01
r 1
2.5V Lamp 6SCL1
r 6
2-Snap Wire 6SC02
r 1
Battery Holder -
uses
2 1.5V type AA (not included)
6SCB1
r 3
3-Snap Wire 6SC03
r 1
Speaker 6SCSP
r 1
4-Snap Wire 6SC04
r 1
Music
Integrated Circuit
6SCU1
r 1
5-Snap Wire 6SC05
r 1
Alarm
Integrated Circuit
6SCU2
r 1
6-Snap Wire 6SC06
r 1
Space War
Integrated Circuit
6SCU3
r 1
Whistle Chip 6SCWC
r 1
r 1
Motor
Fan
6SCM1
6SCM1F
r 1
Slide Switch 6SCS1
r 1
100Ω Resistor 6SCR1
r 1
Press Switch 6SCS2
r 1
r 1
Jumper Wire (Black)
Jumper Wire (Red)
6SCJ1
6SCJ2
r 1
Photoresistor 6SCRP
You may order additional / replacement parts at our
website: www.snapcircuits.net
WC
6
5
4
3
2
1
S1
S2
RP
M1
U3
U2
U1
SP
B1
L1
D1
R1
-2-
Parts List (Colors and styles may vary) Symbols and Numbers
