Project 132 2-Light Symphony of Sounds
This circuit is similar to to project 126 (Symphony of Sounds), but
adds the lamp (L1). Note that the lamp does not snap on the battery
holder (B1), but is secured by the 2-snap wire on level 3.
Turn on the slide switch (S1); you hear sounds from the music &
alarm ICs (U1 & U2), and the color LED (D8) and lamp light. Push
the press switch (S2) several times to add sounds from the space
war IC (U3).
You can also use the variants in projects 127-131 here.
A B C
D
Project 133
Super Symphony of
Sounds
This circuit is similar to to the preceding circuit, but also adds
the motor (M1) and glow fan. Note that the speaker (SP2)
does not snap on the battery holder (B1), but is secured by
the 2-snap wire on level 3.
Turn on the slide switch (S1); you hear sounds from the music
& alarm ICs (U1 & U2), the color LED (D8) & lamp (L1) light,
and the motor spins the glow fan. Push the press switch (S2)
several times to add sounds from the space war IC (U3).
You can also use the variants in projects 127-131 here.
A B C
D
!
WARNING: Moving parts. Do not touch the fan or motor during operation.
Do not lean over the motor. Fan may not rise until switch is released.
+
