Use and maintenance manual
Page 105
Engineering Department PHONE: +39 0532 829 965 - FAX: +39 0532 829 177
E-Mail: support@elenos.com
5. ELECTRICAL SCHEMATICS - 5.6. RF final output stage
Ref. DescriptionParts list
C1 56pF
C2 10nF
C3 10nF
C4 10nF
C5 10nF
C6 10nF
C7 10nF
C8 10nF
C9 10nF
C10 10nF
C14 470pF
C11 470pF
C12 470pF
C15 470pF
C16 470pF
C17 470pF
C18 470pF
C19 470pF
C13 47uF 63V
D1 1N4148
J1 SMA CS VERT
J2 BNC
L1 IND
L2 430nH
L3 70uH
P1 20K
R6 10K
R1 10K
R2 10
R3 10
R4 10
R5 10
R8 10
R9 10
R7 22
TF1
TF2 25 ohms
TF3 25 ohms
TF4 50 ohms
U1 BLF278
