●Projector Overview
1
1
2
3
7 8
4
5
6
1. Power on / o button
2. Ventilation slots
3. Focus ring
4. Projector lens
5. Ventilation slots
6. Charge LED (charge blue, full o)
7. Ventilation slots
8. Stand hole (1/4inch)
1
2
32 4 5 6 7
Warning tips:
It’s strictly prohibited to block the air intake window.
This may cause over heating and damage the projector.
1. Speaker
2. IR Remote control receiver
3. AUX cord jack (Earphone jack)
4. HDMI port
5. USB port
6. Master Switch
7. Micro USB Charging port
2
