39
A B
L9= 0 : 40mm
L9
45mm
L9= 40 : 80mm
85mm
L9= 80 : 120mm
123mm
L9= 120 : 160mm
2x
3,5x9,5mm
1x
38
A B
4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ELICA RULES Series and is the answer not in the manual?

ELICA RULES Series Specifications

General IconGeneral
TypeWall-mounted
Grease FilterAluminium
Noise Level65 dB(A)
Number of Motors1
MaterialStainless Steel
Energy ClassA
Width90 cm
ControlsTouch
LightingLED 2x2.5W
