Fig. 6
Fig. 7
4. Adjusting Top Black Masking (shown in Fig. 8-12)
Note: All electric screens come with standard top black masking and they cannot be dropped further.
DO NOT use these instructions to try to get more out of your standard black masking drop. Use these
instructions only if you have decreased the nsmount of your black masking and need to increase it back.
When you turn the UP switch, the screen
will retract correspondingly. Stop rotating
the switch once the weight bar lines up
with the casing. (Warning: If you continue
to rotate the switch once the weight bar
fits flush with the casing, the screen will
attempt to retract further, causing
damage to the unit. DO NOT over turn the
switch.)
If the screen retracts too far, just
rotate the UP adjustment switch
2-3 turns clockwise and the
screen will lower.
