Elkay Quartz - Page 2

OPENING IN
11/16" RADIUS
SINK PROFILE
CABINET
BASE
COUNTERTOP
RECESSED 1/8"
(3 SIDES)
32.750"
18-1/8"
FROM
CABINET
FRONT
FIGURE 2
COUNTERTOP
COUNTERTOP
FIGURE 1
Installation Instructions
Elkay
2222 Camden Court
Oak Brook, IL 60523
©2017 Elkay
Printed in Germany
elkay.com
(Rev B 4/17) 1000004012
RECOMMENDED
FASTENERS LOCATIONS
Designed to affix to the underside of any solid surface countertop.
UNDERMOUNT - 1/8" REVEAL
Silicone Caulk
(not furnished)
Mounting Clip
Fastener
(not furnished)
Sink
Countertop
1/8"
(3mm)
Feature for Top Mount version
(not used in Undermount model)
