ELMECO B Large Series User Manual

- 27 -
F
GB
#
CODES/CODES
DESCRIPTION
DESCRIPTION
1
B0004107-002
JOINT D'ETANCHEITE MANCHON OR2106
FOOD SYLICON SLEEVE HOLDING GASKET OR2106
2
B0004101-001
MANCHON QUICKREAM
QUICKREAM SLEEVE
3
B0000110-001
BROCHE CYLINDRIQUE 4X35MM INOX A2
STEEL CYLINDRICAL PLUG 4X35MM
4
B0003108-002
RACCORD DROIT LEVIER NYLON NOIR
BLACK NYLON RIGHT LEVER CONNECTION
5
B0003106-001
AXE JONCTION RACCORDS DELRIN + LAITON
CONNECTIONS JUNCTION AXSIS
6
B0003111-001
JOINT GORGE ROBINET SILICONE DE156
SILICON TAP RELIEF GASKET DE156
7
B0003109-003
PISTON EVACUATION COMPLET QUICKREAM
QUICKREAM COMPLETE DRAIN PISTON
8
P0006105-001
VIS TC CROIX M4X10MM INOX
STEEL SCREW
9
B0003107-002
RACCORD GAUCHE LEVIER NYLON NOIR
BLACK NYLON LEFT HANDLE BRIDGE
10
B0003120-001
LEVIER EVACUATION QK AVEC BROCHE
QK HANDLE COMPLETE OF CYLINDER PIN
11
B0006109-002
COUPOLE TRANSPARENTE AVEC CLE DE BLOCAGE
TRANSPARENT COVER WITH KEY LOCK
12
B0000102-003
BAC TRANSPARENTE QUICKREAM + MANCHON
QUICKREAM TRANSPARENT TANK COMPLETE OF SLEEVE
13
L0000106-001
JOINT BAC BB/QK
TANK GASKET BB/QK
14
M0000107-001
BAGUE FIXATION HELICE VERTICALE BOUT + INOX
VERTICAL BLADE FIXING RING
15
B0000106-001
ARBRE TRANSMISSION ECROU INOX
STEEL SHAFT WITH STEEL NUT
16
B0004105-002
HELICE VERTICALE + DOUILLE INOX + ENGRENAGE QK
VERSION 2014
QUICKREAM VERTICAL AUGER + BUSHING + GEAR 2014 VERS.
17
B0006113-001
CLE DEBLOCAGE COUPOLE
COVER UNLOCK KEY
18
M0000104-001
DOUILLE FOURREAU TRANSMISSION BOUT
TRANSMISSION SHAFT BUSHING
19
B0000103-003
FOURREAU TRANSMISSION QK AVEC DOUILLE
QUICKREAM TRANSMISSION SHAFT WITH BUSHING
20
A0000114-001
JOINT TORIQUE FOURREAU TRANSMISSION
TRANSMISSION SHAFT GASKET
21
M0004105-002
PIGNON HELICE HORIZONTALE VERSION 2014
HORIZONTAL AUGER GEAR 2014 VERS.
22
M0004102-002
DOUILLE HELICE HORIZONTALE VERSION 2012
HORIZONTAL AUGER BUSHING 2012 VERS.
23
L0004103-002
HELICE HORIZONTALE BB AVEC DOUILLE VERSION 2012
BIG BIZ HORIZONTAL AUGER COMPLETE OF BUSHING 2012
VERS.
24
M0000120-001
ECROU CARRE D5 FER ZN UNI 5597
D5 SQUARE NUT
25
M0006103-003
CHARNIERE POSTERIEURE NYLON NOIR
BLACK NYLON REAR HINGE
26
L0002113-004
ENSEMBLE BAC BIG BIZ NOIR
BIG BIZ COMPLETE BLACK TANK
27
M0001101-001
VIS TE A BRIDE 5X12 ZINGUEE
TE GALVANIZED SCREW 5X12
28
M0000105-001
BAGUE FIXATION FOURREAU BOUT + LAITON
SHAFT FIXING RING
29
M0005139-001
ENSEMBLE MOTOREDUCTEUR AVEC CELLULE DE HALL
COMPLETE GEAR MOTOR WITH HALL SENSOR
30
A0000117-001
DOUILLE CENTRAGE MOTOREDUCTEUR / ARBRE
GEAR MOTOR BUSHING
31
DADOD.6ZFL
ECROU M6 A BRIDE
M6 NUT
35
A0001104-001
BROCHE MOTOREDUCTEUR/ARBRE TRANSMISSION
GEARMOTOR/TRANSMISSION SHAFT PIN
36
M0000157-002
SONDE THERMOSTAT ELECTRONIQUE COMPLETE
ELECTRONIC THERMOSTAT PROBE COMPLETE
37
B0003112-002
JOINT TORIQUE SILICONE PISTON OR3118
PISTON SILICON GASKET OR 3118
38
M0006115-003
CHARNIERE ANTERIEURE NYLON NOIR
BLACK NYLON FRONT HINGE
39
M0006116-003
BASE NYLON NOIR
BLACK NYLON BASE
40
M0006102-003
CROCHET CHARNIERE NYLON NOIR
BLACK NYLON HINGE HOOK
41
M0006119-001
POIGNEE FIXATION CROCHETS M5X25 mm
SPLINED KNOB
100
A0000115-001
VIS TE A BRIDE M5X20MM
SCREW TE M5X20MM
108
B0003115-001
BROCHE BLOCAGE RESSORT
SPRING LOCKING PIN
109
B0003119-001
ETRIER REDUCTION OUVERTURE ROBINET
OPENING TAP REDUCTION BRACKET
110
B0003118-001
RESSORT FERMETURE ROBINET
TAP CLOSING SPRING BRACKET
112
B0006113-002
CLE SERRURE COUPOLE BLARGE+
TOP LIGHT COVER KEY
113
A0006132
COUPOLE LED BLARGE+
BLARGE+ TOP LIGHT COVER
114
A0006133-001
BAGUE NOIRE PORTE-ECROU POUR LED BL+
BLACK RING FOR NUT
115
AE005101-001
LAMPE 18 LED 12VAC BLARGE+
BLARGE+ LEDS LIGHT 12VAC
116
A0005118-001
SUPPORT LED/COUPOLE NOIR BLARGE+
BLACK BRACKET FOR LEDS AND COVER
117
A0000126-001
VIS TC+ M3X8 INOX
M3X8 STEEL SCREW
118
VTTC2.9X9.5CR
VIS TC CROIX AUTO-TARAUDEUSE 2.9X9.5
2.9X9.5 SELF-TAPPING SCREW
119
A0006134-001
DESSOUS COUPOLE TRANSPARENT BLARGE+ AVEC
SERRURE
BLARGE+ TRANSPARENT COVER FOR TOP LIGHT
