UM600183 Rev. A, page 25 of 38
User Manual – I-series 2.0
BCR state
value
ELOPeripheralManager.BCR_STATE_DEVICE_CONNECTION
1 << 0
ELOPeripheralManager.BCR_STATE_DEVICE_DISCONNECTION
1 << 1
ELOPeripheralManager.BCR_STATE_DATA_RECEIVIED
1 << 2
ELOPeripheralManager.BCR_STATE_PIN_AUTO_DISABLE
1 << 3
GPIO state
value
ELOPeripheralManager.GPIO_STATE_HIGH
1 << 4
ELOPeripheralManager.GPIO_STATE_LOW
1 << 5
GPIO data
gpio81
gpio82
Table 3-2
