ELSEM A
433MHz Keyring Remote with Frequency Hopping – PentaFOB
®
Series
PentaFOB
®
Programming Instructions
Coding the PentaFOB
®
remotes and receivers can be done in 2 different ways.
1. Using the Receiver
2. Using another Remote Control
Coding using the Receiver
1. Check that all switches are “OFF” on the receivers 12-way dip switch
2. Press and hold the program button on the receiver
3. Press the remote button for 2 seconds, receiver LED will flash and then turn Green
4. Release the button on the receiver and the remote
5. Press remote control button to test the receiver output
Deleting Receivers Memory
Short the Code Reset pins on the receiver for 10 seconds. This will delete all the remotes from the
receiver’s memory.
