ElyQ Vision 50 - Page 11

Main Frame Assembly (Part 1.02)
Ely
Q
BAG EQ3009
Glue width: approx. 1mm
Blue
Locktite
S003-4 Vision 50 - Competition / Italy 13-05-2009
22
19
22
Blue
Locktite
Blue
Locktite
Socket screw M3x38 (x2)
Socket screw M3x22 (x8)
Socket screw M3x8 (x12)
Socket screw M3x6 (x29)
Socket screw M2x4 (x2)
Lock Nut M2.5 (x2)
Lock Nut M3 (x2)
Washer d3,D8,W1.5 (x12)
Socket screw M2.5x8 (x6)
Socket B.H. screw M3x8 (x8)
22
23
30
27
26
28
29
24
15
25
23
23
20
Blue
Locktite
Blue
Locktite
Preview (V50 Competition)
23
25
17
23
17
