Item Code Description Q.ty
1 8107400B Tail Pulley Flange (Metal) 1
2 8107500B 8107500B+8107900B Tail Pulley (Metal) 1
3 8001200B Tail pitch control lever 1
4 8001300B Tail housing (L) 2
5 8001400B Tail housing (R) 2
6 8001600A Tail unit housing (R) 1
7 8001700A Tail unit housing (L) 1
8 8107300A Tail Pitch Control Fork (Metal) 1
9 8001900A Tail pitch control link 2
10 8002000A Tail rotor control slider ring 1
11 8100900C Tail rotor hub SUS 1
12 8101300A Tail rotor shaft 1
13 8101500A Pin 2x12 1
14 8101600A Self Tapping Ball type A 2
15 8101700A Pin 2x10 2
16 8101800A Collar d2, D3, W4.3 2
17 8101900A Collar d3, D4, W10 1
18 8102000A Tail pitch slider bushing 1
19 8201300A Flat washer d3, D5, W0.5 1
20 8200100A Self tapping screw 3x18 1
21 8200200A Set screw M3x4 1
22 8600400A Bearing d5, D11, W5 2
23 8600500A Bearing d5, D10, W4 2
24 8200300A Self tapping screw 2x10 2
25 8201800A Socket Screw M3x8 2
26 8204800A Flat washer d7.5, D10, W0.5 2
27 8600600A Bearing d6, D10, W3 2
28 8200600A E-ring 4
29 8204700A Socket screw M2.5x8 4
30 8200800A Lock nut M2.5 4
31 8601100A Bearing d4, D7, W2.5 2
32 8601800A Thrust Bearing d5, D10, W4 2
33 8205600A Washer d3, D8, W0.75 2
34 8201900A Socket Buttom Head Screw M3x8 1
