ElyQ Vision 50 - Tail Assy (BAG EQ3007-21)

10
12
12
14
11
10
10
9
8
7
6
6
5
4
3
2
1
1
1
Tail Assy
Ely
Q
Preview
Vision 50 - Competition / Italy 13-05-2009S012-2
11
13
13
Lock Nut M3 (x4)
11
14
Socket screw M3x14 (x2)
13
Washer d3,D8,W1.5 (x4)
10
Selftapping screw 3x12 (x4)
12
Socket screw M3x30 (x3)
Item Code Description Q.ty
1 8000800A Tail control guide 3
2 8002200A Horizontal fin clamp lower 1
3 8002300A Horizontal fin clamp upper 1
4 8002500A Horizontal Stabilizer CF 1
5 8002600A Vertical Stabilizer CF 1
6 8002700A Ball link A 2
7 8006000A 686XL Tail Drive Belt 1
8 8009200A Tail Boom V50 with Logo (Carbon Fiber) 1
9 8105900A SUS Rear Servo ROD 620mm (L-V2) 1
10 8200000A Self tapping screw 3x12 4
11 8200400A Lock nut M3 4
12 8201700A Socket screw M3x30 3
13 8201200A Flat Washer d3,D8,W1.5 4
14 8200900A Socket screw M3x14 2
BAG EQ3007-21
