ElyQ Vision 50 - Page 41

3
2
4
8
1
5
1
6
7
8
Mixing Lever Assy
Large Internal Diameter
always go toward the
main Rotor HUB
Small Internal Diameter
always go toward the Blade
Grease
Grease
Main Rotor Pitch Assy
Ely
Q
3
2
4
8
1
5
Item Code Description Q.ty
1 8601000A Bearing d6, D13, W5 4
2 8202100B Washer d9, D13, W0.5 2
3 8601300A Thrust bearing d6, D12, W4.5 2
4 8201300A Flat Washer d3, D5, W0.5 2
5 8106400A Main Blade Grip Arm V50 Alu 2
6 8106300A Main Blade Grip V50 Alu 2
7 8201800A Socket Screw M3x8 2
8 8203800A Socket Screw M3x16 4
Item Code Description Q.ty
1 8601000A Bearing d6, D13, W5 4
2 8202100A Washer d6, D10, W0.5 2
3 8601300A Thrust bearing d6, D12, W4.5 2
4 8201300A Flat Washer d3, D5, W0.5 2
5 8106400A Main Blade Grip Arm V50 Alu 2
6 8106300A Main Blade Grip V50 Alu 2
7 8201800A Socket Screw M3x8 2
8 8203800A Socket Screw M3x16 4
Preview
1
6
7
8
Mixing Lever Assy
S017-2
Large Internal Diameter
always go toward the
main Rotor HUB
Small Internal Diameter
always go toward the Blade
Grease
BAG EQ3014
Grease
AB
B
A
Vision 50 - Competition / Italy 13-05-2009
Glue width: approx. 1mm
Blue
Locktite
Blue
Locktite
Blue
Locktite
Blue
Locktite
7
Socket screw M3x8 (x2)
Blue
Locktite
Blue
Locktite
Blue
Locktite
Socket screw M3x16 (x4)
8
