Ely
Q
Fuel Tank Assy
BAG EQ3000
6
5
4
3
2
1
S001-2 Vision 50 - Competition / Italy 13-05-2009
1 8003100A Fuel tank stopper 1
2 8004400A Fuel tank nipple 1
3 8010900A Fuel tank (V50c) 1
4 8011000A Silicon fuel tube L=80mm d2.5, D6 1
5 8103600A Fuel Clunk 1
6 8402000A Fuel Tank Assy
