ElyQ Vision 50 - Page 51

Ely
Q
Main Rotor Blades
S021-2
Preview
Item Code Description Q.ty
1 8203500A Main Grip Socket Screw M4x27 (17+10) 2
2 8203100A Lock nut M4 2
3 8010800A Fuel Tank Rubber Seal 500mm (V50c) 1
1
2
3
2
D
B
A
C
Blades not included
BAG EQ3018
Vision 50 - Competition / Italy 13-05-2009
Socket Screw M4x27 (17+10) (x2)
1
Lock Nut M4 (x2)
2
Cyano
acrylate
3
Cyano
acrylate
A - L = 55mm
B - L = 80mm
C - L = 86mm
D - L = 20mm
A=55mm
D=20mm
B=80mm
C=86mm
01020304050607080
