em-vent EVSCP24-5 - Specific Characteristics; Technical Specifications Summary; DIP Switch Features

Technical Note
November 2014 | Version 1
Specific Characteristics
Specifications
EVSCP24-5
Approvals / Conforms
EN 12101-10: 2005 approved and certified – class A (double
supply) – envir. Class 1 (to -15˚C)
Conform to EN 12101-9
Power Supply
230V AC – max 1.5A
Output Supply
24V DC
Motor Outputs
1 pc. (line detection: 1-4 lines)
Max Total Load
5A
Operating Temperature
-15˚C - +40˚C
Density
IP 54
Battery Back-up (72hrs)
Yes
Batteries
2 pcs. 12V7, 2AH
Dimensions (WxDxH)
Weight incl. Batteries
238x113x286mm
7.5kg
Colour
White Front / Grey Indication Label
Fire Groups
1 pc. with line detection
Max power consumption for fire switches (LED+Buzzer) = 6.6mA =
approx. 3 manual control points
Comfort Groups
1 pc. - unlimited no. of comfort switches
Detector (Smoke/Heat) Input
1 pc. with line detection
Max power consumption for detectors = 2.2mA = approx. 22
detectors
Weather Sensor Input / Close All
Yes
Alarm Output
Yes – potential free contact, max 48V / 0.5A
Failure Output
Yes – potential free contact, max 48V / 0.5A
24V DC for External Use
24V DC / max 0.5A – at 230V AC operation
Bus Communication
Yes – connection of 2-10 control panels – line detection
Visual (LED) Indication in Front Panel
‘OK’ / ‘AC Fault’ / ‘Low Battery’ / ‘Line Fault’ / ‘Alarm’ / ‘Comfort
Open’
DIP Switch Features (Standard)
Service hours (LED’s flash in front panel)
Comfort opening interval
Temperature detection via motor output
Extra line detection via 3 wire motor output
Fail safe (alarm by line failure)
Sprinkler (close by alarm)
Bus comm. settings (react on Bus comm.)
Potential free contact for comfort open
