Embedded Systems LogicMachine5 Datasheet

Embedded Systems SIA © 2021
www.logicmachine.net
LM5p2-RD, LM5p2-RDE
Data sheet / Issue date 26.11.2021
Page 3 / 16
Types of product
LogicMachine5 Reactor Dimmer Power LM5p2-RD
LogicMachine5 Reactor Dimmer Power EnOcean LM5p2-RDE
Standards and norms compliance
EMC: EN61000-6-1
EN61000-6-3
PCT Certificate
Technical data:
Power supply: 12V-30V DC on terminal connectors or
12V-30V DC Passive Power-over-Ethernet
Power consummation: 1.3W
Interface: KNX/EIB TP1 1
DALI master 2 (up to 128 DALI ballasts in
total)
EnOcean 868MH with 1
antenna (optional)
1-Wire 1
10BaseT/100BaseTX 1
RS-485 1
RS-485/RS-232 1
(switchable in software –
full-duplex=RS232,
half-duplex=RS485)
USB2.0 1
Analog input/Digital output 8
380 mA continues current on
output. Optoislated from
KNX/EIB bus
Analog outputs 3 x 0-10 V,
1 x 4..20 mA
Connections: KNX bus Bus Connection Terminal
0.8mm2
Power supply Screw, 1.5mm2
Serial Screw, 1 mm2
I/O Screw, 1 mm2
