EMC2 VNX Series Hardware Information Guide

2 EMC VNX5400 Hardware Information Guide
About this guide
About this guide
This guide is designed for personnel who install, configure, and maintain the VNX5400
platform. To use this hardware publication, you should be familiar with digital storage
equipment and cabling.

Only trained and qualified personnel should be allowed to install, replace, or service this
equipment.
Revision history
The following table presents the revision history of this document:
Revision Date Description
05 February 25, 2015 The following sections were updated:
• SP Power supply (page 31)
• Four-port 16 Gb/s optical FC I/O module
(page 50)
• 3U, 120 (2.5-inch) DAE (“3U, 120
(2.5-inch) DAE (DAE8S)” on page 90)
• Appendix B, Alum-A-Lift (“Appendix B:
Field lift tool and accessory kit” on
page 135)
Miscellaneous edits
04 July 21, 2014 The following sections were updated:
• Hardware features (“Hardware features”
on page 9)
• SP Power supply (page 31)
• Miscellaneous edits
03 January 27, 2014 The following sections were updated:
• Front view of the VNX5400 (Figure 1 on
page 7)
• Rear view of the VNX5400 (Figure 2 on
page 8)
• Hardware features (“Hardware features”
on page 9)
• Two-port 10 GbE RJ-45 Base-T I/O module
(page 24, page 56, and page 57)
• SP Power supply (page 31 and page 32)
•I/O module (“I/O modules” on page 44)
• Miscellaneous edits
02 October 11, 2013 Updated Table 4 on page 19.
01 July 23, 2013 First release of the
VNX5400 Hardware
Information Guide
