20040326 1-17-8 T8001EL
CRT CBA
SW1208 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH SKHHAM or SST0101AL029
TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
SW1209 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH SKHHAM or SST0101AL029
TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
SW1210 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH SKHHAM or SST0101AL029
TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
SW1211 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH SKHHAM or SST0101AL029
TACT SWITCH KSM0612B or SST0101HH003
TACT SWITCH TC-1104(H=5.0) SST0101DNG02
MISCELLANEOUS
BC1571 BEAD INDUCTORS FBA04HA600VB-00 LLBF00STU026
BC1601 PCB JUMPER D0.6-P5.0 JW5.0T
BC1602 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC1605 PCB JUMPER D0.6-P5.0 JW5.0T
BC1606 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC1607 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC1650 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC1731 PCB JUMPER D0.6-P5.0 JW5.0T
BC1732 PCB JUMPER D0.6-P5.0 JW5.0T
BC1736 PCB JUMPER D0.6-P5.0 JW5.0T
BC1737 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
CF1031 CERAMIC TRAP 4.5MHz or FBE455PMR003
4.5M TRAP XT4.5MB2 or FBE455PLN001
CERAMIC TRAP 4.5MHz FBE455PMS002
CF1032 CERAMIC FILTER SFSRA4M50CF00-B0 or FBB455PMR004
4.5M FILTER LTH4.5MCB FBB455PLN001
F1601# FUSE 4.00A/125V or PAGU20CAG402
# FUSE 51MS040L or PAFC20CHV402
# FUSE STC4A125V U/CT or PAGE20CW3402
# FUSE 4.00A/125V PAGG20CNG402
FH1601 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER FH-V-03078 XH01Z00DK001
FH1602 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER FH-V-03078 XH01Z00DK001
JK1701 RCA JACK(YELLOW) MTJ-032-05B-20 or JXRL010LY038
RCA JACK 1P:YELLOW DA1-05A3N0S001 JXRL010RP036
JK1702 RCA JACK(RED) MTJ-032-05A-21 or JYRL010LY010
RCA JACK 1P:RED(SW) DA1-05A2N1S001 JYRL010RP017
JK1703 RCA JACK(WHITE) MTJ-032-05B-22 or JXRL010LY039
RCA JACK 1P : WHITE DA1-05A4N0S001 JXRL010RP037
JK1730 RCA JACK MSP-241V-05 PBSN W/O JXRL010LY085
JK1801 MINI JACK HSJ2000-01-010 or JYSL010HD002
MINI JACK MSJ-2000 or JYSL010LY003
PHONE JACK DP3-25-7-001 JYSL010RP002
PS1602# THERMISTOR ZPB45BL7R0A QNZZ45BL7R0A
RS1201 REMOCON RECEIVE UNIT PIC-37042SR or USESJRSKK034
REMOCON RECEIVE UNIT PIC-26042SR-2 USESJRSKK032
SA1601# SURGE ABSORBER JVR-07N471K or NVQZVR07N471
# SURGE ABSORBER CNR-10D471K or NVQZR10D471K
# SURGE ABSORBER CNR-07D471K or NVQZR07D471K
# SURGE ABSORBER PVR-07D471KB NVQZ07D471KB
SF1001 SAW FILTER SAFHM45M7VAAZ00B03 FBB456PMR010
SG1601# GAP. FNR-G3.10D FAZ000LD6005
T1571# FLYBACK TRANSFORMER JF0501-3101B or LTF00CPXB039
Ref. No. Description Part No.
# FLYBACK TRANS BSC23-2603S LTF00CPS2054
T1572 H0RIZONTAL DRIVE TRANS LP2-005 LTH00CPA5005
T1601# SWITCHING TRANS 04727 LTT00CPKT137
TB4 13V H/V HEAT SINK PIU T8001UB 0EM302039
TB5 9V POW HEAT SINK PHC T4400UA 0EM407598
TL2 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TP1301 PCB JUMPER D0.6-P10.0 JW10.0T
TP1304 PCB JUMPER D0.6-P5.0 JW5.0T
TP1305 PCB JUMPER D0.6-P5.0 JW5.0T
TP1401 PCB JUMPER D0.6-P10.0 JW10.0T
TP1402 PCB JUMPER D0.6-P10.0 JW10.0T
TP1403 PCB JUMPER D0.6-P7.5 JW7.5T
TP1404 PCB JUMPER D0.6-P7.5 JW7.5T
TP1405 PCB JUMPER D0.6-P7.5 JW7.5T
TP1501 PCB JUMPER D0.6-P5.0 JW5.0T
TP1502 PCB JUMPER D0.6-P5.0 JW5.0T
TP1503 PCB JUMPER D0.6-P5.0 JW5.0T
TP1731 PCB JUMPER D0.6-P12.5 JW12.5T
TP1732 PCB JUMPER D0.6-P7.5 JW7.5T
TP1733 PCB JUMPER D0.6-P7.5 JW7.5T
TP1734 PCB JUMPER D0.6-P7.5 JW7.5T
TU1001 TUNER B9015AF or UTUNNTUSP025
TUNER ENV56K02G3 or UTUNNTUMS012
TUNER UNIT TEQH9-001A UTUNNTUAL032
VR1601 CARBON P.O.T. 10k Ω B VRCB103HH014
W1601# AC CORD PB8K9F9110A-057 or WAC0172LW008
# AC CORD WAC0172LTE01 or WAC0172LTE01
# AC CORD WAC0172AS006 or WAC0172AS006
# AC CORD LA-2366 or WAC0172LW006
# AC CORD A0A0280-007 WAC0172LTE04
X1301 X'TAL 3.579545 MHz or FXD355LLN003
X'TAL 3.579545MHz(30PPM) FXD355LCHE01
Ref. No. Description Part No.
CRT CBA
Consists of the following
--------
CAPACITORS
C501 CERAMIC CAP. B K 1000pF/2KV or CCD3DKP0B102
CERAMIC CAP. B K 1000pF/2KV or CA3D102MR030
CERAMIC CAP. B K 1000pF/2KV CCD3DKD0B102
C502 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C511 CHIP CERAMIC CAP. B K 390pF/50V CHD1JKB0B391
C521 CHIP CERAMIC CAP. B K 390pF/50V CHD1JKB0B391
C531 CHIP CERAMIC CAP. B K 470pF/50V CHD1JKB0B471
CONNECTORS
CN505 PIN CONNECTOR 005P-5100 or JTEA001TG001
CONNECTOR PIN, 1P LV or 1700576
CONNECTOR PIN, 1P RT-01N-2.3A 1730688
COIL
L501 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q511 TRANSISTOR 2SC2482 TPE6 QQSZ02SC2482
Q521 TRANSISTOR 2SC2482 TPE6 QQSZ02SC2482
Q531 TRANSISTOR 2SC2482 TPE6 QQSZ02SC2482
RESISTORS
R510 METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
Ref. No. Description Part No.
