WF13
Q503
Collector
Q503
Base
WF5 WF14
Q502
Collector
Q502
Base
WF4 WF15
Q501
Collector
Q501
Base
WF3
7-15 BL6406F01011-2
7-16
CRT CBA Top View CRT CBA Bottom View
CRT
Ref No. Position
Q501
B-2
Q502
B-2
Q503
B-2
CN501 A-1
WH301B B-1
WH501B B-1
TRANSISTORS
CONNECTORS
