Emerson EWT19S3 - Page 38

EXPLODED VIEWS
Cabinet
11-1 11-2 L6406CEX
B2
B2
B8
B8
B2
B2
B6
B6
B1
L2
L2
L3
L2
L2
L2
A4
A3
B5
V501
CRT CBA
ANODE CAP
Part of Flyback
Transformer
DY551
CLN551
DY551
V501-1
Details for DY551
and surrounding parts
SHINWHA
TAPE SGT-730
(WHITE)
SHINWHA
TAPE SGT-730
(BLACK)
SCOTCH
TAPE #880
SCOTCH
TAPE #880
SCOTCH
TAPE #880
V501-2
See Electrical Parts List
for parts with this mark.
DG691
A1
B3
A2
L1
B4
SP801
CLN801
B9
L1
B7
SP802
CLN802
B9
PB2
PL1
PL1
PB3
PB1
MAIN CBA
AC601
L1
B1
