Instruction Manual
D103296X012
2052 Actuator
June 2017
2
Table 1. Fisher 2052 Actuator Specifications
Specifications
Actuator Mounting Connections
Splined shaft connection, ISO 5211 actuator‐to‐bracket connection
Size 1: F07, Size 2: F10, Size 3: F14
Actuator Sizes See table 2
Operating Pressure
(1)
See table 3
Maximum Diaphragm Casing Pressure Size 1, 2, and 3 Actuators: 5 barg (73 psig)
Pressure Connection See table 5
Torque Output See table 3
Actuator Temperature Capabilities
(1)
Standard: -45 to 80_C (-50 to 176_F)
Optional: -45 to 100_C (-50 to 212_F)
(3)
or -60 to 80_C (-76 to 176_F)
(4)
Operation Field reversible between PDTC and PDTO; right‐ and left‐hand mounting, any angle of orientation
Approximate Weight
Size 1: 22.2 kg (49 lb)
Size 2: 54.4 kg (120 lb)
Size 3: 113 kg (250 lb)
Controller/Positioners Available DVC2000, DVC6020, DVC6030, DVC6200, 3610J, 3620J, 4190, C1
Adjustable Travel Stops Standard adjustable up and down stops capable of 30 degrees of adjustment per stop.
Accessories Available
846, 646, 2625, and 67C Series, switches, i2P-100, VBL, DXP, GO Switch™
Handwheel
Top‐mounted handwheel: Optional on Size 1, 2, and 3 actuators
Declutchable handwheel: Optional on Size 1, 2, and 3 actuators
Operational Lockout
(2)
Available for customer‐supplied padlock to lock the actuator in the spring‐fail position
1. The pressure/temperature limits in this manual should not be exceeded. The current SIL certification for the 2052 actuator is only relevant for the standard temperature ratings shown.
2. Lockout and declutchable handwheel cannot be used together on size 2 and size 3 actuators.
3. Temperature range only applies when using silicone diaphragm material. Silicone diaphragm is not available with the top-mounted handwheel option.
4. Temperature range requires use of stainless steel bolting for yoke and travel stops. Not available with top-mounted handwheel.
Table 2. Actuator and Shaft Size Availability
SHAFT SIZE ACTUATOR SIZE
mm Inches 1 2 3
12.7 1/2 X
14.3 x 15.9 9/16 x 5/8 X X
15.9 5/8 X X
19.1 3/4 X X X
22.2 7/8 X X
25.4 1 X X
28.6 x 31.8 1-1/8 x 1-1/4 X X
31.8 1-1/4 X X
31.8 x 38.1 1-1/4 x 1-1/2 X
38.1 1-1/2 X
39.7 x 44.5 1-9/16 x 1-3/4 X
44.5 1-3/4 X
50.8 2 X
Table 3. Torque versus Actuator Size
ACTUATOR
SIZE AND
ACTION
OPERATING PRESSURE
2 barg (29 psig)
(1)
3 barg (44 psig)
(1)
4 barg (58 psig)
(1)
4.7 barg (68 psig)
(1)
Torque
NSm lbfSin NSm lbfSin NSm lbfSin NSm lbfSin
1 (PDTO)
1 (PDTC)
25.5
25.5
226
226
25.5
36.2
226
320
51.2
51.2
453
453
51.2
72.4
453
641
2 (PDTO)
2 (PDTC)
105
105
930
930
105
175
930
1550
210
210
1860
1860
210
320
1860
2840
3 (PDTO) 327 2890 327 2890 631 5580 631 5580
3 (PDTC) 280 2480 557 4930 584 5170 930 8230
1. Do not interpolate between operating pressures. Consult your Emerson sales office or Local Business Partner for assistance.
