20100205 14-8 A01F4EL
D1972 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1973 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1990 DIODE FAST RECOVERY 31DF4-FC QDWZ031DF4FC
D1994 DIODE ZENER 1ZB100BB NDWZ001ZB100
ICS
IC1000 IC PULSE-WIDTH-MODULATION CONT
TL494CDR
NSCA0T0TY006
IC1700 IC BA10324AF-E2 QSZBA0TRM032
IC1930# PHOTO COUPLER LTV817MCF NPECLTV817MF
IC1931# PHOTO COUPLER LTV817MCF NPECLTV817MF
TRANSISTORS
Q1001 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1003 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1004 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1005 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1060 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1061 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1110 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1111 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1160 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1161 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1210 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1211 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1500 FET MOS 2SK2417(FT) QFWZSK2417FT
Q1501 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1502 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q1503 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1550 FET MOS 2SK2417(FT) QFWZSK2417FT
Q1551 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1552 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q1553 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1600 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1621 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1800 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1801 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1802 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1803 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1804 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1815 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q1930# MOS FET TK7A50D QEWZTK7A50DQ
Q1931# TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1932# TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1970 NPN TRANSISTOR KTC3200-GR-AT/P NQSGKTC3200P
Q1971 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1972 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
RESISTORS
R1001 CHIP RES. 1/10W F 22k Ω RRXAFR5H2202
R1002 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1003 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1004 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1005 RES CARBON FILM T 1/4W J 220k Ω RCX4224T1001
R1006 RES CARBON FILM T 1/4W J 56k Ω RCX4563T1001
R1007 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1008 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1009 CHIP RES. 1/10W J 82k Ω RRXAJR5Z0823
R1010 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1011 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1012 CHIP RES. 1/10W F 24k Ω RRXAFR5H2402
R1013 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1014 CHIP RES. 1/10W F 4.7k Ω RRXAFR5H4701
R1015 CHIP RES. 1/10W F 7.50 k Ω RRXAFR5H7501
R1016 CHIP RES. 1/10W J 120k Ω RRXAJR5Z0124
R1017 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
Ref. No. Description Part No.
R1018 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1019 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R1021 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1022 CHIP RES. 1/10W F 2.2k Ω RRXAFR5H2201
R1023 CHIP RES. 1/10W F 3.3k Ω RRXAFR5H3301
R1024 CHIP RES. 1/10W F 100k Ω RRXAFR5H1003
R1026 CHIP RES. 1/10W F 220 Ω RRXAFR5H2200
R1028 CHIP RES. 1/10W F 36k Ω RRXAFR5H3602
R1030 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1031 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R1032 RES CARBON FILM T 1/4W J 24k Ω RCX4243T1001
R1033 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1034 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1035 RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R1036 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1040 METAL OXIDE FILM RES. 2W J 0.39 Ω RN02R39ZU001
R1041 RES CARBON FILM T 1/4W J 33k Ω RCX4333T1001
R1043 RES CARBON FILM T 1/4W J 12k Ω RCX4123T1001
R1044 METAL OXIDE FILM RES. 2W J 0.39 Ω RN02R39ZU001
R1050 METAL OXIDE FILM RES. 1W J 15k Ω RN01153ZU001
R1051 METAL OXIDE FILM RES. 1W J 15k Ω RN01153ZU001
R1060 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1061 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1062 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1063 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1064 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1065 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1066 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1067 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1068 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1069 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1070 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1071 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1072 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1080 CHIP RES. 1/10W F 22k Ω RRXAFR5H2202
R1081 CHIP RES. 1/10W J 5.6k Ω RRXAJR5Z0562
R1110 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1111 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1112 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1113 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1114 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1115 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1116 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1117 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1118 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1119 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1120 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1121 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1122 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1160 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1161 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1162 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1163 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1164 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1165 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1166 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1167 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1168 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1169 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1170 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1171 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1172 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1210 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
Ref. No. Description Part No.
