20100401 14-15 A01FACA
PARTS LIST [LC320EM1 (Serial No. : DS2A)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Different parts from the original model
LC320EM1 (Serial No. : DS1A)
Ref. No. Description Part No.
A10# RATING LABEL A01FAUH ----------
CL201 WIRE ASSEMBLY 15PIN FFC 15PIN 140MM WX1A01F4-102
CL1003 WIRE ASSEMBLY 11PIN FFC 11PIN 129MM WX1A01F4-101
L16 SCREW TAP TIGHT M3X10 BIND HEAD+BLK
NI
GBHS3100
LCD1 LCD MODULE IPS ALPHA 6BIT UJ32AXA
S5 SERIAL NO. LABEL A01PBUH ----------
X2# OWNERS MANUAL A01F4UH 1EMN25720A
To Next Page
