Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
32MF301B/F7 (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL ASSEMBLY
Consists of the following
A17FJMMA-001
DIGITAL MAIN CBA UNIT A17FJMMA-001-DM
FUNCTION CBA UNIT A17FJMMA-001-FN
IR SENSOR CBA UNIT A17FJMMA-001-IR
POWER SUPPLY CBA A17F8MPW-001
C602 CAP ELECTROLYTIC 390µF/200V CEB391DYG006
C603 Not used
C604 Not used
CN600# Not used
CN601# CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
D611 Not used
D635 Not used
R605 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R606 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R642 RES CHIP 1608 1/10W F 75.0k Ω RTW7502HH008
B41 HEAT SINK PNB ASSEMBLY A01FNUT 1EM432598
FH601 FUSE HOLDER MSF-015-RS-SN (B110) XH001Z0LY001
FH602 FUSE HOLDER MSF-015-RS-SN (B110) XH001Z0LY001
To Next Page
