TYPE B
PARTS LIST [LC320SS2 (Serial No.: ME1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Different parts from the original model
32MF301B/F7 (Serial No.: DS1)
Ref. No. Description Part No.
STAND ASSEMBLY A17F8UT 1ESA28630
A1 FRONT CABINET A17F2UH 1EM226004A
A12# RATING LABEL A17FBUT ----------
A15 Not used
A42 ENERGY GUIDE LABEL A17F2UH ----------
AC600# AC CORD W/O A GND WIRE UL/CSA/1730/NO/
BLACK
WAC1720LW006
B11 SPEAKER HOLDER A17F1UH 1EM126473
B27 Not used
B63 Not used
B64 Not used
B66 Not used
B67 Not used
B72 Not used
CL3101 WIRE ASSEMBLY 2PIN 2PIN/250MM/BLACK
RED
WX1A17F1T217
CL3102 WIRE ASSEMBLY 7PIN 7PIN/600MM/BLACK
RED
WX1A17F1T216
L28 STAND SCREW KIT A17F8UT 1ESA28631
L42 SHOULDER SCREW A01Q0UF 1EM328277
LCD1 LCD MODULE 31.5INCH WIDE CMI 31.5INCH UK32MXG
SP3801 SPEAKER MAGNETIC S0412F28E DS08130XQ004
SP3802 SPEAKER MAGNETIC S0412F28E DS08130XQ004
S1 CARTON A17FLUT 1EM436626
S7 STAND BAG A01FKUT 1EM432498
X2# OWNERS MANUAL A1778UT 1EMN28748
X3 REMOTE CONTROL NH210UD NH210UD
X4 BATTERY DRY R03(SIZE AAA ) XB00M0RKT001
X6 QUICK START GUIDE A17FLUT 1EMN28881
X7 REGISTRATION CARD (SYLVANIA) A17N2UT 1EMN27762
To Next Page
