2011/12/05 14-1 A17F0CA.fm
TYPE A
PARTS LIST [32MF301B/F7 (Serial No.: DS1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
STAND ASSEMBLY A17F1UH 1ESA27585
A1 FRONT CABINET A17F0UH 1EM226003B
A2 REAR CABINET A17F1UH 1EM027006B
A4 FUNCTION KNOB A17F1UH 1EM226223A
A8 JACK HOLDER A17F1UH 1EM225384A
A11 SENSOR LENS A17N1UH 1EM329957
A12# RATING LABEL A17F0UH ----------
A15 ENERGY STAR LABEL A91F2UH ----------
A42 ENERGY GUIDE LABEL A17F0UH ----------
AC600# AC CORD W/O A GND WIRE UL/CSA/1700/NO/
BLACK
WAC1720LW005
B5 STAND BRACKET A17F1UH 1EM225385
B11 SPEAKER HOLDER A17F1UH 1EM125714
B18 GASKET A8AF0UH 1EM425861
B22 WALL MOUNT BRACKET A84N0UH 1EM323797
B27 CLOTH(10X180XT0.5) L0336JG 0EM408827
B63 CONNECTOR COVER A17F1UH 1EM331137
B64 CLOTH(10X90XT1.0) A7120UH 1EM424258
B66 CLOTH(15X30XT1.0) B7507UH 0EM402452
B67 CUSHION A17F1UH 1EM435678
B72 CLOTH 15X10XT0.5 1EM420293
CL200 FFC WIRE ASSEMBLY 11PIN/110MM WX1A17F1-101
CL632 FFC WIRE ASSEMBLY 19PIN/295MM WX1A17F1-102
CL3005 FFC WIRE ASSEMBLY 24PIN/213MM WX1A17F1-104
CL3101 WIRE ASSEMBLY 2PIN 2PIN/250MM/BLACK
RED
WX1A17F1T205
CL3102 WIRE ASSEMBLY 7PIN 7PIN/600MM/BLACK
RED
WX1A17F1T206
CL3801 WIRE ASSEMBLY 2PIN 2PIN/150MM/BLACK
RED
WX1A17F1L301
CL3802 WIRE ASSEMBLY 2PIN 2PIN/480MM/BLACK
RED
WX1A17F1R302
L1 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L14 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L15 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L25 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
L28 STAND SCREW KIT A17F1UH 1ESA27587
L27 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
LCD1 LCD MODULE 31.5INCH 31.5INCH UK32MXB
SP3801 SPEAKER MAGNETIC S0412F28A DS08130XQ001
SP3802 SPEAKER MAGNETIC S0412F28A DS08130XQ001
PACKING
S1 CARTON A17F0UH 1EM434844
S3 STYROFOAM TOP A17F1UH 1EM027385
S4 STYROFOAM BOTTOM A17F1UH 1EM027386
S5 SET BAG A17F6UH 1EM330877
S6 SERIAL NO. LABEL A01PBUH ----------
S7 STAND BAG A94F0UH 1EM428757
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A17F0UH 1EMN27701A
X3 REMOTE CONTROL NF805UD NF805UD
X4 DRY BATTERY R03/2S XB0M451T0006
X6 QUICK START GUIDE A17F0UH 1EMN27702A
X7 REGISTRATION CARD (MAGNAVOX)
A17N0UH
1EMN27759
Ref. No. Description Part No.
