Emerson LC320EM82 Service Manual

8-3
A71FFSCP1
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
CN301
10
2 12.2
3 12.2
43.4
50
65.0
75.0
89.2
90
10 5.1
11 5.1
12 5.1
13 0
14 3.2
15 0
16 2.5
17 0
18 15.6
19 0
20 34.6
21 0
22 3.2
23 1.1
VOLTAGE CHART
Pin No. Voltage
Power Supply 1/2 & Digital Sub Schematic Diagram
