Emerson Rosemount 3100 Series Reference Manual

Reference Manual
00809-0100-4840, Rev CB
Appendix A: Reference Data
February 2015
77
Reference Data
Appendix A Reference Data
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 77
Dimension drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 84
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 87
Spare parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 90
A.1 Specifications
A.1.1 General
Product
Rosemount 3100 Series Liquid Level Transmitters:
 Rosemount 3101: Level
 Rosemount 3102:
Level, Distance, Content (Volume) and Flow measurement, with two integral signal relays
 Rosemount 3105:
Level, Distance, Content (Volume) and Flow measurement, for hazardous locations
Measurement principle
Ultrasonic, time-of-flight
A.1.2 Measuring performance
Measurement range
Rosemount 3101: 1 to 26 ft (0,3 to 8 m)
Rosemount 3102: 1 to 36 ft (0,3 to 11 m)
Rosemount 3105: 1 to 36 ft (0,3 to 11 m)
Accuracy under reference conditions
(1)
Rosemount 3101:
± 0.2 in. (5 mm) for < 3.3 ft. (1 m), ± 0.5% of measured distance for > 3.3 ft. (1 m)
Rosemount 3102 and Rosemount 3105
(2)
:
± 0.1 in. (2,5 mm) < 3.3 ft (1 m), ±0.25% of measured distance for > 3.3 ft. (1 m)
(1) Temperature: 68 °F (20 °C), Pressure: 1013 mbar (atmospheric pressure), and Relative Humidity: 50%.
(2) GOST-approved 3102 and 3105: see the Russian product data sheet 00813-0107-4840 for revised accuracy of measured distances less than 3.3 ft. (1 m).

Emerson Rosemount 3100 Series Specifications

General

Brand	Emerson
Model	Rosemount 3100 Series
Category	Transmitter
Language	English
