EMG PA2 - Triple Pickup Configuration Details; Wiring with Passive Tone Control; Wiring with Active Tone Control

Installation Instructions:
EMG Model: PA2 Control
PA2 No Switch Instructions Page 4
Diagram #7
3 Pickups
One Master Volume
One SPC Control
One Tone (Active VLPF)
One PA2 No Switch
Diagram #6
3 Pickups
One Master Volume
One Tone (Passive)
One SPC Control
One PA2 No Switch
VOLUME CONTROL
TONE CONTROL
(PASSIVE)
SPC CONTROL
OUTPUT TO JACK
NOTE:
REVERSED
CONNECTOR
VOLUME CONTROL
TONE
(ACTIVE VLPF)
SPC CONTROL
OUTPUT TO JACK
NOTE:
REVERSED
CONNECTOR
NOTE:
REVERSED
CONNECTOR
PA2
PA2
