EMKO EZM-3735 - Page 4

2.2 Panel Cut-Out
2. General Description
2.1 Front View and Dimensions of EZM-3735 Digital Timer
Mounting Clamp
Panel Surface
(maximum thickness 15 mm / 0.59 inch)
Front Panel
IP65 protection
NEMA 4X
4
76 mm / 3 inch
6 mm / 0.24 inch
34,5 mm / 1.36 inch
65 mm / 2.56 inch
Maximum 15 mm / 0.59 inch
110 mm / 4.33 inch (min)
71 mm / 2.79 inch
29 mm / 1.14 inch
50 mm / 1.97 inch (min)
P
S
h
s
m
START
STOP
ü
PAUSE
