2. INSTALLATION2. INSTALLATION
2.2 Electrical power supply
The appliance must be connected in observance of the standard
regarding electrical systems in the country where it is to be
installed.
In Italy the reference standard is CEI 64-8.
- The air curtain is supplied with 230 Volt, (± 10%) 50 Hz.
- The appliance is supplied with an electrical plug of the “SUKO”.
Warning!
Connect the appliance to the ground observing the local application
rules.
Attention
It is possible to connect a microswitch to the DOOR SWITCH terminals. When this microswitch is connected, it allows automatic activation of the air jet at
each opening.
If not used, be sure to provide a jumper between the two terminals.
ACI 907 - 1207 ACI 1607
MOTOR
CAPACITOR
CAPACITOR
2.3 Wiring diagram
