16
A
High Beam Indicator
When the headlight high beam is on this indicator. Remains on until the high beam is
turned off.
B
Left Turning Signal
Flashes when the left turning signal is turned on. This arrow remains flashing until the
turning signal is canceled.
C
Battery Strength Indicator
Indicates the current battery strength. (Note: the accurate battery level is shown at full
throttle instead of when the bike is still.)
D
Right Turning Signal
Flashes when the right turning signal is turned on. This arrow remains flashing until
the turning signal is canceled.
E
Odometer
Total travel distance of the bike (can not be reset).
F
Speed Mode Indicator
Indicates the speed level (this function may not be available for certain models).
G
Current Speed
Indicates the real-time speed of the bike.
c� Speedometer
Description
km/h
km
V
1. Schematic Diagram
