Emos H8010 - Page 6

6
Wiring Diagram | Example of Most Common Connection for Lock
Control
(see Fig. 3, 4)
Conductor Description
1 – Red 12 V + power supply
2 – Black 12 V – power supply
3 – Brown Door contact
4 – Orange Exit button 1 (activates relay contact without code)
5 – Yellow Exit button 2 (activates relay contact without code)
6 – Blue Relay 2 contact – NO (normally-open)
7 – Purple Relay 2 contact – COM
8 – Grey Relay 2 contact – NC (normally-closed)
9 – White Relay 1 contact – NO (normally-open)
10 – Pink Relay 1 contact – COM
11 – Turquoise Relay 1 contact – NC (normally-closed)
12 – Green GND
Do not dispose with domestic waste. Use special collection points for sorted waste.
Contact local authorities for information about collection points. If the electronic
devices would be disposed in landll, dangerous substances may reach ground-
water and subsequently food chain, where it could aect human health.
Emos spol s.r.o. declares that the H8010/H8011 is in compliance with the essential
requirements and other relevant provisions of Directive.
The device can be freely operated in the EU.
The Declaration of Conformity can be found at http://www.emos.eu/download.
CZ | Vstupní kódová klávesnice
Popis:
(viz obr. 1)
1 – Indikátor sepnutí relé
2 – Indikátor stavu
3 – Klávesnice
4 – Připevňovací šroub
Instalace:
(viz obr. 2)
Popis funkcí:
Zóna 1: (Relé 1 – primární)
– Slouží pouze k ovládání spínacího relé.
– Adresy 000–999 (1 000 kódů).
Zóna 2: (Relé 2 – sekundární)
– Slouží k ovládání 2. spínacího relé, nebo jako tlačítko zvonku k zazvonění (přepí-
natelná funkce).
– Adresy 00–09 (10 kódů).
