Assembly
26
Attach the transport wheels MM with the screws KK
and washers LL to the lower side of the housing.
Set the upper shield B onto the housing rod F and
attach with the screws CC.
Attention! Do not fully tighten the screws yet.
Using DD set G on to H.
Set the burner H onto the housing K and attach with
the screws AA and BB.
V2/2018-EM01020
1
2
3
EN
