Step 5(a): No solar

Main CT installation

Open the clasps on the CTs and place each

clamp around one of the main service cables.

Then, shut the clasps to secure the CTs.

IMPORTANT! The Breaker → imprint on the

bottom of the CTs should point toward the

breakers. Finally, insert the screw terminal

plugs into the ports on the right side of the

monitor. To avoid clutter, unscrew the 22

AWG wires from the screw terminals, cut

them to size, and reattach them ensuring the

black and white wires match the icons on the

front of the Vue.

DANGER: The service

mains are energized!

Breakers

Meter
