Page #14 background imageLoading...
Page #14 background image
14
SPECIFICATIONS
MODEL NUMBER
EC52FX730V3
EC52FX730V3CA
EC60FX730V3
EC60FX730V3CA
EC52FX730V5
EC52FX730V5CA
EC60FX801V5
EC60FX801V5CA
WEIGHT & DIMENSIONS
52”
60”
Width without Deck
49.8”
55.0”
Width Deflector Up
52.8”
61.1”
Width Deflector Down
65.4”
73.6”
Length
76.6”
79.4”
Height ROPS Up
68.6”
68.6”
Height ROPS Down
46.6”
46.6”
Wheelbase
47.0”
49.75”
Curb Weight
1112
1051
ENGINE
Kawasaki FX730V
Kawasaki FX801V
Specs: See your Engine Owner’s Manual
RPM: High Idle: 3600
Low Idle: 1550
FUEL SYSTEM
Capacity: 14 Gal
Type of Fuel: Regular Unleaded Gasoline
87 Octane or higher
Fuel Filter: In-line
ELECTRICAL SYSTEM
Charging System: 12 Volt, 15 Amp @
3600 RPM
Battery Type: Group Ul
Battery Class: 350 CCA Minimum
Battery Voltage:12V DC
Polarity: Neg. Ground
Fuses: (2) 20A
TRANSMISSION
Two Hydro Gear® integrated transaxles
Hydraulic Oil: 20w-50 Non- Synthetic
Speed:
o ZT-3400
0-9.6 mph Fwd
0-5.0 mph Reverse
o ZT-5400
0-12.0 mph Fwd
0-5.0 mph Reverse
CUTTING DECK
Cutting Width: 52” or 60”
Discharge: Side
Blade Size: 52”:18” ; 60”:20.5(3 ea)
Deck Drive: Electric Clutch
Deck: 7 ga Welded Steel Floating Deck
Deck Depth: 5.5
Cutting Height 1.0” to 5.5”Adjustment:
Mulching Kit: Optional
TIRES
Front: 13 x 6.50-122 Smooth
Pressure 12-14 psi (83-97 kPa)
Rear: WYK52FX730V5 (CA) 24 X 9.5-12
EC60FX801V5 24 X 12.0-12
EC60FX801V5 (CA) ) 24 X 12.0-12
Pressure 15 psi (103 kPa)
