17
DECK LIFT PEDAL
Located at the right front corner of the floor pan.
Push the pedal forward with your foot to raise
the cutting deck. Allow the pedal to move
rearward to lower the cutting deck to the cut
height that has been set.
TRANSPORT LOCK
Located at rear of height of cut plates on RH
side of floor pan. Transport pawl engages side
link when deck is raised to up-stop, preventing
deck from being lowered. To lower deck, apply
pressure to foot pedal, pull rearward on pawl
handle, and reduce pressure on foot pedal until
deck lowers to pre-selected cut height.
BLADE ENGAGEMENT SWITCH
Located on console.
Switch must be pulled out (up) to engage the
blades. Switch is pushed in to disengage the
blades.
PRE-START
Fill fuel tank on level ground. For best results
use only clean, fresh regular grade unleaded
gasoline with an octane rating of 87 or higher.
IMPORTANT: Never use methanol, gasoline
containing methanol, gasohol containing
more than 10% ethanol, premium gasoline,
or white gas because the fuel system could
be damaged.
Do Not add oil to gasoline
Do Not over fill fuel tank. Fill the fuel tank to
the bottom of the filler neck. The empty space
in the tank allows gasoline to expand.
Overfilling may result in fuel leakage or damage
to the engine or emission system.
Make sure you understand the controls, their
locations, their functions, and their safety
requirements.
Refer to the Maintenance section and perform
all the necessary inspection and maintenance
steps.
