4.
Open sealer fully and center jaws of
sealer
over
marks on each seal. Crimp or notch each
seal the proper number of
times by bringing
the top handle
downward as far as it will go.
See
Figure 4.
5.
Release tensioner from strap by bringing
handle down until gripper release cam
locks
in tensioning handle pin. Remove
tensioner
curl and sliding tool away from
strap. See
figure 5.
6.
Use short strokes on tensioning handle: Do not
tension strap when you are in an awkward
position.
TOP OF LOAD OPERATOR
SAFETY
BELTS
RECOMMENDED FOR
HIGH LOADS.
While tensioning strap, do not rotate
the
tensioning handle to the point
where it
will contact the gripper
release cam.
This will result in a loss of strap tension.
FIGURE 4.
RECOMMENDED TENSION HANDLE
OPERATING RANGE
